OTO PHOTONICS INC.
Wavelength range 180-1100nm configurable; Spectral resolution 0.2nm~13nm depends on various grating and slit combination.
Standard unfold Czerny-Turner optical design.
More than 10 different sensors and 30 different gratings for selection.
Excellent thermal (<0.04nm/℃), humidity, vibration and shock stability.
Support continuous high-speed & multiple exposures and trigger modes.
Proprietary stray light calibration algorithm (stray light can be eliminated to 0.01％).
On-board CPU supports optical and color parameters calculation.
A single-chip processer with faster data transfer rate, using along with a high sensitivity sensor achieves a min. exposure time: 6 us and a max. frame rate: 0.2 ms /frame.
Pixel Binning mode supports to increase sensitivity, 2/4/8/16 pixel binning optional.
Dimension: 110 (L) x 86 (W) x 35.4 (H) mm. Fiber input: SMA905 or FC/PC (optional). Data interface: USB 2.0, UART, Ethernet.
